Middle Things Fiber Bridge 10 12G

Middle Things Fiber Bridge 10 12G

_x000D_

The Fiber Bridge 10 splits a Neutrik opticalCON MTP® 24 fiber cable into 10 different OpticalCON Duo pairs + 2 LAN, and vice versa (reversible).  It supports 3G / 6G / 12G signals.

_x000D_



_x000D_

- Stage box with reversible design

_x000D_

The Fiber Bridge 10 allows you to have only one cable running from the control room to the stage. On the stage, the Fiber Bridge 10 acts as a stage box that splits the Neutrik opticalCON MTP® 24 fiber cable into 10 different OpticalCON Duo pairs + 2x LAN, and vice versa. You can also use it in reverse and merge 10 OpticalCON Duo pairs + 2x LAN into one single  opticalCON MTP® 24 fiber cable . It supports 3G / 6G / 12G signals.

_x000D_

- Can run with zero power

_x000D_

The Fiber Bridge is a passive splitter, meaning that no power is required to operate it. However, if you plan to use the LAN connections, you need to provide +12V DC power using the barrel jack connector.

_x000D_

- Rugged fiber connector

_x000D_

The opticalCON MTP® 24 connector makes the Fiber Bridge compatible with the rugged opticalCON MTP® 24 cable drums by Neutrik, designed for field use and tough handling. The connector has a built-in automatic shutter that protects the 12 fiber cores as soon as the cable is disconnected.

_x000D_

- Many possibilities with the Middle Fiber products

_x000D_

Paired with a Fiber Dispatch , a Fiber Unite or a Fiber Camera Box,, unleash many configurations that will greatly improve your day to day multicamera workflow!

_x000D_

In the Box

_x000D_

_x000D_
• 1x 1U Fiber Bridge 10
_x000D_

_x000D_



_x000D_

Compatibility

_x000D_

The Fiber Bridge 10 can be used with the Fiber Bridge 10, Fiber Dispatch 5, and Fiber Camera Box. It supports single mode LC optical fiber cables, as well as Neutrik OpticalCon Duo and OpticalCon Duo Lite cables. The MTP® 24 connector  supports opticalCON MTP® 24 Cables.

_x000D_

Technical Specifications

_x000D_

_x000D_
• I/O connections: 10x Neutrik OpticalCON Duo, 1x Neutrik opticalCON MTP® 24, 2x LAN ,+12V DC power.
_x000D_
• Input Voltage : 12V DC
_x000D_
• Power Consumption :
_x000D_
• Fiber type : Single Mode
_x000D_
• LAN support : 10/100/1000Mbps Full/Half Duplex
_x000D_
• Power Consumption :
_x000D_
• Height : 4.5cm / 1.8 inch
_x000D_
• Width : 48cm /18.9 inch
_x000D_
• Depth : 22.5cm / 8.9 inch
_x000D_
• Weight : 2.5kg / 5.5 lbs
_x000D_
• Storage Temperature : 14 to 140°F / -10 to 60°C
_x000D_
• Package Weight : 3kg  / 6.6  lb
_x000D_
• Box Dimensions (LxWxH) : 52cm x 25cm x 8cm | 5”x 9.84” x 3.15”
_x000D_

_x000D_



_x000D_

Warranty

_x000D_

Limited 1-Year Manufacturer Warranty
